| Project | Unit | ZWY-60/22L | ZWY-30/18.5L |
| Loading capacity | m³/h | 60 | 30 |
| Dig width A | mm | ≥3680 | ≥3200 |
| The digging distance is B | mm | ≥1620 | ≥1500 |
| Dig high degree C | mm | ≥2600 | ≥2200 |
| Dig depth D | mm | ≥500 | ≥500 |
| Unloading high degree E | mm | 1 5 0 0 ( 可 变 ) | 1 4 0 0 ( 可 变 ) |
| Minimum unloading height F | mm | 1 3 6 0 ( 可 变 ) | 1 2 0 0 ( 可 变 ) |
| Unloading distance G | mm | ≥1360 | ≥870 |
| Maximum rotation Angle H | o | ±45 | ±30 |
| Ground clearance | mm | ≥180 | ≥160 |
| Average ground contact pressure of the track | MPa | ≤0.1 | ≤0.1 |
| Minimum turning radius of the track | m | ≤3 | ≤2.5 |
| Climbing ability | o | ≥25 | ≥25 |
| Scraper speed | m/s | ≥0.42 | ≥0.42 |
| Walking speed | m/s | ≥0.29 | ≥0.15 |
| Rated working pressure | MPa | 15 | 15 |
| Motor power | kW | 22(30) | 18.5(22) |
| Overall machine quality | kg | 6300±300 | 3800±200 |
| Transportation status Maximum external dimensions |
mm | 6130±50 | 4820±50 |
| mm | 1575±50 | 1250±50 | |
| mm | 2100±50 | 1720±50 |
